TracoPower TBA 2-1223 DC/DC converter 2W 65mA 2 outputs

TracoPower TBA 2-1223 is a DC-DC converter designed to provide dependable performance and efficiency in current rectification and conversion applications. With a power rating of 2 watts and the ability to deliver a current of up to 65 milliamperes, this converter features two outputs, allowing for flexible power distribution in complex circuitry. Engineered for precision, it is ideal for use in printed circuit boards where reliable power regulation is required, such as in industrial automation systems, telecommunications equipment, and portable electronics. The compact design of the TBA 2-1223 facilitates easy integration into existing electronic assemblies, making it a practical choice for engineers focused on scalability and performance.

Connection	Solder pins
Content	1
Dimensions	(L x W x H) 19.60 x 7.60 x 10.20 mm
Efficiency (max.)	84%
Height	10.20mm
Insulation Voltage	1500V DC
Length	19.60mm
Max. output current	65mA
Maximum Input Volage	13.20V DC
Maximum Operating Temperature	90°C
Minimum Input Volage	10.8V DC
No. of outputs	2
Operating temperature (min.)	-40°C
Output current (max.) - rounded	65mA
Power	2W
Product Type	DC/DC converter (print)
Type	TBA 2
Weight	2.80g
Width	7.60mm
