TracoPower TBA 2-1222 DC/DC converter 80mA 2W 2 outputs

TracoPower TBA 2-1222 is a DC-DC converter specifically designed for applications requiring reliable power conversion in compact spaces. This device delivers a power output of 2 watts and supports up to 80 mA current to facilitate efficient energy conversion across two outputs. It is engineered for seamless integration into printed circuit boards, offering a versatile solution for electrical and electronic systems that require dual-output voltage regulation. With its robust design, the TBA 2-1222 is suitable for various industrial and commercial applications, including telecommunications, instrumentation, and distributed power architectures, where stabilised voltage levels are essential. This current rectifier device ensures optimal performance in systems requiring precise voltage transformation and isolation.

Connection	Solder pins
Content	1
Dimensions	(L x W x H) 19.60 x 7.60 x 10.20 mm
Efficiency (max.)	83%
Height	10.20mm
Insulation Voltage	1500V DC
Length	19.60mm
Max. output current	80mA
Maximum Input Volage	13.20V DC
Maximum Operating Temperature	90°C
Minimum Input Volage	10.8V DC
No. of outputs	2
Operating temperature (min.)	-40°C
Output current (max.) - rounded	80mA
Power	2W
Product Type	DC/DC converter (print)
Type	TBA 2
Weight	2.80g
Width	7.60mm
