TracoPower TBA 1-1221E DC/DC converter 100 mA 1 W 2 outputs

TracoPower TBA 1-1221E is a versatile DC-DC converter designed for efficient power conversion in electronic applications. This component provides a total power output of 1 watt and supports a maximum current of 100 mA across its dual output channels. It is engineered to offer reliable performance in compact and cost-sensitive designs, making it suitable for use in printed circuit boards where space is at a premium. With its ability to convert direct current from one voltage level to another, the TBA 1-1221E is ideal for powering isolated circuits, managing different voltage requirements in complex systems, and enhancing overall energy distribution efficiency in telecommunications, industrial automation, and consumer electronics products. The converter is supplied as a single unit, ensuring precise integration within electronic assemblies.

Connection	Solder pins
Content	1
Dimensions	(L x W x H) 19.50 x 6 x 9.50 mm
Efficiency (max.)	79%
Height	9.50mm
Insulation Voltage	1500V DC
Length	19.50mm
Max. output current	100mA
Maximum Input Volage	13.20V DC
Maximum Operating Temperature	95°C
Minimum Input Volage	10.8V DC
No. of outputs	2
Operating temperature (min.)	-40°C
Output current (max.) - rounded	100mA
Power	1W
Product Type	DC/DC converter (print)
Type	TBA 1E
Weight	2.30g
Width	6mm
