TracoPower TBA 1-0510 TBA DC/DC converter 260 mA 1 W 1 output

TracoPower TBA 1-0510 is a reliable DC-DC converter designed for applications requiring efficient power management. This print-mounted converter supplies 1 watt of power with a maximum output current of 260 mA from a single output. It is particularly suited for use in electronic circuits where space is limited, yet precise voltage regulation is necessary. Typically employed in industrial, telecommunications, and instrumentation systems, it facilitates efficient energy conversion from one DC voltage level to another, ensuring operational stability in diverse engineering environments. The TracoPower TBA 1-0510 offers a dependable solution for engineers seeking robust and compact DC-DC conversion technology.

Output Voltage	3.3V DC
Power Rating	1W
Connection	Solder pins
Content	1
Dimensions	(L x W x H) 11.70 x 6 x 9.70 mm
Efficiency (max.)	75%
Height	9.70mm
Insulation Voltage	1500V DC
Length	11.70mm
Max. output current	260mA
Maximum Input Volage	5.50V DC
Maximum Operating Temperature	95°C
Minimum Input Volage	4.5V DC
No. of outputs	1
Operating temperature (min.)	-40°C
Output current (max.) - rounded	260mA
Output voltage (max.)	3.3V DC
Output voltage (min.)	3.3V DC
Power	1W
Product Type	DC/DC converter (print)
Type	TBA 1
Weight	1.60g
Width	6mm
