TE Connectivity PS 801 87713-000 Position Switch Adjustable 10W Reed

Image Representative of Range

TE Connectivity PS 801 87713-000 Position Switch Adjustable 10W Reed

TE Connectivity Sensor
Standard range
Order Code:

13-0909

Brand: TE Connectivity Sensor MPN: PS 801 EAN-13: 4064161261133
Qty Unit Price (Ex VAT)
1+ £35.72
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
684 in stock, despatched in 4 working days

The TE Connectivity Sensor PS 801 is a position switch designed for screwing into plastic and stainless steel materials, featuring a 10-watt reed contact. Manufactured by Gentech, this sensor has a stainless steel M10x65mm housing and includes a 1.5-metre double-insulated cable. It is typically used for flow or fill level sensing, as well as door contact applications.
Type Reed switch
Cable length 1.50m
Connection Open end cable
Contact type 1 maker
IP rating IP67
Material (details) Stainless steel
Max. switching capacity 10W
Max. temperature +120°C
Min. temperature -30°C
Misc Attribute 1 Stainless steel M10 x 65 mm with 1.5 m double-insulated cable
Misc Attribute 2 87713-000
Switching capacity 10W
Switching current (max.) 1A
Temperature range -30 - +120°C
