TE Connectivity ADE08S04 DIP SW SPST 8Pos SMD Ext Act DIP/SIP Switch

MPN: ADE08S04
Brand: TE Connectivity
Order Code: 15-6162
Country of Origin: China

RoHS Compliant
Free UK shipping available

Inc VAT

Qty	Unit Price (Ex VAT)
200+	£1.11

Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT

Order in multiples of 200

Available to back orderBack order, lead time 4 months

Product Details
Quick Quote

TE Connectivity's ADE08S04 is a highly reliable DIP switch.

It features a single-pole single-throw configuration with eight positions.

The switch is designed for surface mounting with an extended actuator.

Common applications include circuit board settings and configuration adjustments.

Circuit	SPST
Number of Positions	8
Current Rating	100mA
Voltage Rating	24VDC
Actuator Type	Extended Actuator
Actuator Length	0.99mm
Actuator Material	Polyamide
Contact Material	Copper Alloy
Contact Plating	Gold
Electrical Life	1000Cycles
Max Operating Temperature	85°C
Max Voltage Rating (DC)	24v
Min Operating Temperature	-30°C
Mount	Surface Mount
Orientation	Straight
Package Quantity	20
RoHS Compliant	Yes
Series	AD
Terminal Pitch	2.54mm
Termination	SMD/SMT
Throw Configuration	SPST
