TE Connectivity 7-1768042-8 STD05W-5 Cable Marker Imprint 5 Ø2.3-3mm

TE Connectivity's STD05W-5 pre-printed cable marker, product number 7-1768042-8, is designed for cable diameters ranging from 2.30 to 3 mm. Utilised primarily for efficient cable identification in industrial labelling applications, this heat shrink product ensures durable marking. The marker is typically employed in environments where reliable and permanent labelling is essential for cable management and organisation.

Type	Pre-printed cable marker
Colour	White
Material	Polyacetal (POM)
Colour-coded	Yes
Halogen-free	Yes
Imprint	5
Max Cable Diameter	3mm
Maximum Operating Temperature	106°C
Maximum Temperature	+106°C
Min. temperature	-40°C
Minimum Operating Temperature	-40°C
Misc Attribute	Numbers
Mount	Cable
Number of labels	30
Outside diameter range	2.30 up to 3mm
Series	STD05
Suitable for outside Ø (min.)	2.30mm
Wire/Cable Diameter	3mm
