TE Connectivity 5161390-4 DIP Switch 4POS SPST 2.54mm

Inc VAT

Qty	Unit Price (Ex VAT)
100+	£2.70

Sign in for personalised pricing

Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT

Order in multiples of 100

Despatched within 5 working days - 4,700 in stock

TE Connectivity's 5161390-4 is a 4-position DIP switch designed with SPST contacts.

It features a 2.54mm pitch, ideal for compact circuit designs.

These switches are commonly used in setting configurations and functions in various electronic devices.

Its easy-to-use design is perfect for prototyping and development applications.

Type	DIP & SIP Switches
Circuit	SPST
Number of Positions	4
Current Rating	25mA
Voltage Rating	24VDC
Actuator Type	Standard
Pitch	2.54mm
Actuator Material	Polyester
Contact Base Material	Phosphor Bronze
Contact Current Rating	500mA
Contact Material	Bronze
Contact Plating	Tin
Contact Post Length	0.1259inch
DC Rated Voltage	50v
Depth	9.9mm
ELV	Compliant
Flammability Rating	UL94 V-0
Height	0.334inch
Housing colour	Natural
Length	0.499inch
Maximum Operating Temperature	70°C
Minimum Operating Temperature	-25°C
Mount	Through Hole
Operating Temperature Range	-25 – 70
Operating Voltage	50
Orientation	Straight
Package Quantity	1000
Packaging	Box
Packaging Method	Box & Carton
Packaging Quantity	500
PCB Contact Termination Area Plating Material	Tin
Product Height	.334
Product Length	12.7
Product Orientation	Vertical
Radiation Hardening	No
RoHS Compliant	Yes
Sealable	No (Without)
Terminal Pitch	2.54mm
Termination	PC Pins
Termination Post & Tail Length	.126
Throw Configuration	SPST
UL Flammability Rating	UL 94V-0
Washable	No
Width	9.9mm
