The TE Connectivity 282843-2 is a PCB mount terminal block with a 90-degree angle, designed for easy integration into circuit boards.
This unshrouded 2-position connector facilitates secure electrical connections.
It is typically used in industrial and consumer electronic applications.
The component is ideal for applications requiring reliable power or signal connections to printed circuit boards.
| Pitch |
10.16mm |
| No. of Ways |
2 |
| Mounting Type |
Through Hole |
| Mounting Direction |
Vertical |
| Wire Gauge (AWG) |
30 to 14AWG |
| Wire Termination |
Rising Clamp |
| Centerline (Pitch) |
10.16mm |
| Circuit Application |
Power & Signal |
| Colour |
Green |
| Connection |
Print |
| Connector & Contact Terminates To |
Printed Circuit Board |
| Connector Mounting Type |
Board Mount |
| Connector orientation |
Perpendicular (to the PCB) |
| Connector System |
Wire-to-Board |
| Contact Base Material |
Brass |
| Contact Current Rating (Max) |
17.5 |
| Contact Material |
Brass tin plated |
| Contact Mating Area Plating Material |
Tin (Sn) |
| Cross section (flexible) (max.) |
1.50mm² |
| Cross section (flexible) (min.) |
0.03mm² |
| Cross section (inflexible) (max.) |
2.50mm² |
| Cross section (inflexible) (min.) |
0.03mm² |
| CS |
10.16mm |
| Current Rating |
17.5A |
| Factory colour |
Green |
| Height |
15.20mm |
| Housing Material |
PA 66 |
| No. of Levels |
1 |
| Number of Positions |
2 |
| Number of Rows |
1 |
| Operating Temperature Range |
-40 – 230 |
| Operating Voltage |
600 |
| Packaging Quantity |
200 |
| Pins per row |
2 |
| Primary Product Color |
Green |
| Product Orientation |
Vertical |
| Termination Method to PCB |
Through Hole - Solder |
| Termination Method to Wire & Cable |
Clamp & Screw |
| Termination Post & Tail Length |
.138 |
| Thread Size |
M3 |
| Type |
Screw terminal |
| Voltage Rating |
600V |
| Width |
9mm |
| Wire Size |
30 – 12 |
