TE Connectivity 207463-1 AMPLIMITE HD-20 25-Pin D-SUB Receptacle 180°

The TE Connectivity AMPLIMITE HD-20 (HDP-20) 207463-1 is a D-SUB receptacle with 25 pins. This connector is commonly used in data communications and industrial applications due to its robust design. It features a 180° configuration, providing reliable and secure connections for signals and data transmission.

Type	D-SUB receptacles
Plug / Socket	Socket, vertical vertical
Mounting Type	Panel Mount
No. of Ways	25
Mounting Direction	180 Degree
Connection Angle	180°
Plating Material	Tin
Centerline (Pitch)	2.7432mm
Circuit Application	Signal
Connector & Contact Terminates To	Wire & Cable
Connector System	Cable-to-Cable
Contact Gender	FEMALE
Insulator Material	THERMOPLASTIC
Material (details)	Housing: zinc-plated steel
Mating Retention	With
Mating Retention Type	Mounting Holes
Max Operating Temperature	105
Min Operating Temperature	-55
Misc Attribute	AMPLIMITE HD-20 (HDP-20)
No. of Rows	2
Number Of Connectors	ONE
Operating Temperature Range	-67 – 221
Packaging Method	Package
Packaging Quantity	400
Sealable	No
Shielded	Yes
Termination Method to Wire & Cable	Crimp
Termination Type	CRIMP
Total Number of Contacts	25
UL Flammability Code	94V-0
UL Flammability Rating	UL 94V-0
