TE Connectivity 1721547-4 PCJ-109D3M-WG000M Connector Male Shrouded 9-Pos PCB Mt

Inc VAT

Qty	Unit Price (Ex VAT)
100+	£1.31

Sign in for personalised pricing

Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT

Order in multiples of 100

Despatched within 5 working days - 2,400 in stock

TE Connectivity's PCJ-109D3M-WG000M connector is a male shrouded 9-position component designed for PCB mounting.

This connector provides reliable and secure electrical connections with a robust housing.

It is commonly used in industrial and automation equipment applications.

The product is identified by the manufacturer part number, 1721547-4.

Type	Relay
Number of Positions	9
Mounting Type	Vertical
Coil Current	22.22mA
Coil Resistance	405Ohm
Coil Suppression Diode	No
Contact Arrangement	SPST-NO
Contact Form	1 Form A
DC Coil Voltage	9v
Maximum AC Switching Voltage	250v
Maximum DC Switching Voltage	30v
Maximum Operating Temperature	85°C
Maximum Pick-Up Voltage	6.75VDC
Maximum Switching Current	5a
Maximum Switching Power	150W\|1.25kVA
Minimum Dropout Voltage	0.45VDC
Minimum Operating Temperature	-40°C
Mounting	Through Hole
Number of Terminals	4
Operate Time	10ms
Product Depth (mm)	7
Product Height (mm)	15
Product Length (mm)	20.4
Product Weight (g)	4
Push to Test Button	No
Relay Construction	Non-Latching
Termination Style	PC Pin
