The TE Connectivity plug 1-1827872-4 is a DIN connector with a total of 28 pins, offering reliable electrical connections. It is typically used in applications requiring secure and robust interfacing such as audio equipment, industrial machinery, or telecommunications. Notably, it features durable construction suited for various environments and provides dependable performance in the specified applications.
| Mounting Type |
Termination |
| Plug / Socket |
Plug |
| Approvals |
UL |
| Centerline (Pitch) |
2.0066mm |
| Circuit Application |
Power & Signal |
| Color |
Black |
| Connector & Contact Terminates To |
Printed Circuit Board |
| Connector Body Material |
Plastic |
| Connector Mounting Type |
Board Mount |
| Connector Product Type |
Connector Assembly |
| Connector System |
Wire-to-Board |
| Contact Base Material |
Copper Alloy |
| Contact Current Rating |
3a |
| Contact Current Rating (Max) |
3 |
| Contact Gender |
Male |
| Contact Material |
Copper Alloy |
| Contact Mating Area Plating Material |
Gold (Au) |
| Contact Mating Area Plating Material Thickness |
15 |
| Contact Plating |
Gold |
| Contact Retention |
No (Without) |
| Contact Style |
Straight |
| Contact Type |
Pin |
| Current Rating |
3a |
| Depth |
11.3mm |
| ELV |
Compliant |
| Flammability Rating |
UL94 V-0 |
| Gender |
Male |
| Halogen free |
Halogen Free |
| Header Type |
Fully Shrouded |
| Height |
0.49inch |
| Housing Color |
Black |
| Housing Material |
Polyester GF |
| Length |
15.02mm |
| Mating Alignment |
With |
| Mating Alignment Type |
Keyed |
| Mating Retention |
With |
| Max Operating Temperature |
221°C |
| Max Voltage Rating (AC) |
125v |
| Min Operating Temperature |
-67°C |
| Mount |
Through Hole |
| Number of Contacts |
28 |
| Number of Ports |
1 |
| Number of Positions |
28 |
| Number of Rows |
2 |
| Number of Ways |
28 |
| Operating Temperature (Max) |
221 |
| Operating Temperature Range |
-67 – 221 |
| Orientation |
Straight |
| Package Quantity |
15 |
| Packaging |
Rail/Tube |
| Packaging Method |
Tube |
| Packaging Quantity |
15 |
| PCB Connector Type |
PCB Mount Header |
| PCB Mount Alignment |
Without |
| PCB Mount Orientation |
Vertical |
| PCB Mount Retention |
With |
| PCB Mount Retention Type |
Retention Leg |
| PCB Mounting Orientation |
Vertical |
| PCB Thickness |
0.063inch |
| Pitch |
0.079inch |
| Preloaded |
Yes |
| Primary Product colour |
Black |
| Radiation Hardening |
No |
| Reach SVHC Compliant |
No |
| RoHS Compliant |
Yes |
| Row Spacing |
0.1299inch |
| Sealable |
No |
| Selectively Loaded |
No (Without) |
| Series |
Dynamic D-1100, AMP |
| Shielding |
Unshielded |
| Shrouded |
Yes (With) |
| Strain Relief |
No (Without) |
| Tail Length |
3.05mm |
| Termination |
Solder |
| Termination Method to PCB |
Through Hole - Solder |
| Total no. of pins |
28 |
| Type |
Plug |
| UL Flammability Rating |
UL 94V-0 |
| VDE Tested |
No |
| Voltage Rating |
125v |
| Width |
0.368inch |
