TE Connectivity 1-1825190-0 DIP Switch 12 Positions Shunt Through-Hole

TE Connectivity
Order Code:

15-1460

Brand: TE Connectivity MPN: 1-1825190-0
Qty Unit Price (Ex VAT)
136+ £1.33
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Order in multiples of 136
Available to back orderBack-order availability date - 24/04/2026

The TE Connectivity 1-1825190-0 DIP switch has 12 positions with a shunt configuration and through-hole mounting.

It features a compact design suitable for space-constrained environments.

This switch is often used in circuit board designs for manually setting configurations.

Typical applications include telecommunications, consumer electronics, and industrial control systems.


Type DIP Switch
Number of Positions 12
Current Rating 3a
Pitch 2.54mm
Body Material Thermoplastic
Color Black
Contact Base Material Copper Alloy
Contact Material Copper Alloy
Contact Plating Tin
Contact Post Length 0.15inch
ELV Compliant
Flammability Rating UL94 V-0
Height 2mm
Housing Color Black
Lead Free Lead Free
Length 1.2inch
Max Operating Temperature 105°C
Min Operating Temperature -55°C
Mount Through Hole
Number of Circuits 12
Operating Temperature Range -30 – 85
Operating Voltage 500
Package Quantity 17
Packaging Rail/Tube
Packaging Method Tube
Packaging Quantity 30
PCB Contact Termination Area Plating Material Tin
Product Height 2
Product Length 1.2
Product Orientation Right Angle
Radiation Hardening No
Reach SVHC Compliant Unknown
RoHS Compliant Yes
Series 7600
Terminal Pitch 2.54mm
Termination PC Pin
Termination Post & Tail Length .15
UL Flammability Rating UL 94V-0
Washable Yes
