TE Connectivity 1-1462037-8 IM03TS Industrial Relay 5V DC 2 Change-Overs

Image Representative of Range

TE Connectivity 1-1462037-8 IM03TS Industrial Relay 5V DC 2 Change-Overs

TE Connectivity
Order Code:

07-3385

Brand: TE Connectivity MPN: 1-1462037-8 EAN-13: 2050006505786
Qty Unit Price (Ex VAT)
3+ £1.63
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Order in multiples of 1
816 in stock, despatched in 4 working days

The TE Connectivity 1-1462037-8 is a telecom relay featuring DPDT configuration with 2 Form C contacts for versatile switching.

Designed for through hole mounting, it ensures reliable electrical performance in circuit applications.

Typical uses include telecommunications systems and signal switching devices.

Its compact design facilitates integration into various electronic and industrial setups.


Coil Voltage 5V DC
Contact Configuration 2CO (DPDT)
Actuating System DC
Application(s) SIGNAL
Coil Current 28.1mA
Coil Power 140mW
Coil Resistance 178O
Coil Type Non-Latching
Coil Voltage (AC) 5v
Coil Voltage (DC) 5v
Connection THT
Contact Current Rating 2a
Contact Material Gold (Au)
Contact Plating Gold
Contact Voltage Rating (DC) 220v
Depth 6mm
Dimensions (L x W x H) 10 x 6 x 5.65 mm
ELV Compliant
Height 5.65mm
Lead Free Lead Free
Length 10mm
Max Current Rating 2a
Max Operating Temperature 85°C
Max Voltage Rating (AC) 250v
Max Voltage Rating (DC) 220v
Max. temperature +85°C
Min Operating Temperature -40°C
Minimum Temperature -40°C
Misc Attribute IM03TS
Mount Through Hole, PCB
Mounting Type PCB
Nominal Voltage 5V DC
Number of Contacts 8
Operate Time 3ms
Package/Case DIP
Packaging Rail/Tube
Ratings IP67
Reach SVHC Compliant Unknown
Relay Type Relay
Release Time 3ms
RoHS Compliant Yes
Series IM, AXICOM
Termination PCB
Throw Configuration DPDT
Type Industrial relay
Width 6mm
