TDK-Lambda PXC-M03-48WS24 DC/DC Converter 24V 125mA 5kV AC Isolation

TDK-Lambda
Order Code:

10-7642

Brand: TDK-Lambda MPN: PXC-M03-48WS24 EAN-13: 2050006495735
Qty Unit Price (Ex VAT)
1+ £44.92
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Available to back orderBack order, lead time 11 days

The TDK-Lambda PXC-M03-48WS24 is a DC/DC converter with an output voltage of 24 V and a current capacity of 125 mA. This compact converter is typically used in electronic circuits where voltage conversion is required. Suitable for use in industrial and telecommunications applications, it offers reliable power conversion.
Number of Outputs 1.0
Output Voltage 24V
Output Current 125mA
Mounting Type PCB
Dimensions (L x W x H) 31.8 x 20.3 x 10.2 mm
Efficiency 86.5%
Enclosure DIP 24
Height 10.2mm
Industry Standard Size DIP-24
Input Voltage 75V
Input Voltage Range[DC] / Vdc 18 to 75
Insulation Voltage 5000V AC
Isolation Isolated
Length 31.8mm
Max. output current 125mA
Maximum Output Current / A 0.125
Maximum Output Power / W 3
Min. input voltage 18V
Nominal Input Voltage[DC] / Vdc 48
Operating temperature (max.) +94°C
Operating temperature (min.) -40°C
Option Pinout style B (No remote ON/OFF & no trim pin)
Output Voltage Range[DC] / Vdc Fixed
Package / Mounting PCB mount
Rated Output Voltage[DC] / Vdc 24
Series PXC-M
Terminal Style DIP
Type DC/DC converter (print)
Width 20.3mm
