TDK-Lambda CCG30-48-12D DC/DC Converter 24V 1.25A 30W 1 Output

The TDK-Lambda CCG30-48-12D is a DC/DC converter providing 24 V at 1.25 A and 30 W output. It is compact, reliable, and suitable for applications requiring a single output. Typical uses include industrial and telecommunications equipment.

Output Voltage	24V DC
Input Voltage Range	76V
Power Rating	30W
Output Current	1.25A
Connection	Solder pins
Dim	(L x W x H) 25.4 x 25.4 x 9.9 mm
Efficiency (max.)	91%
Enclosure	DIP 6 (1x1 brick)
Height	9.9mm
Industry Standard Size	1x1 inch size
Input Voltage Range[DC] / Vdc	18 to 76
Isolation	Isolated
Length	25.4mm
Max. output current	1.25A
Maximum Operating Temperature	+85°C
Maximum Output Current / A	1.25 1.25
Maximum Output Power / W	30
Minimum Input Volage	18V
Nominal Input Voltage[DC] / Vdc	24/48
Number of Outputs	1
Operating temperature (min.)	-40°C
Output Voltage Range[DC] / Vdc	Fixed Fixed
Package / Mounting	PCB mount
Power	30W
Rated Output Voltage[DC] / Vdc	0
Series	CCG
Terminal Style	DIP
Type	DC/DC converter (print)
Weight	20g
Width	25.4mm
