Step Relay Finder 20.23.8.230.4000 230VAC 1NO + 1NC Contacts

MPN: 20.23.8.230.4000
Brand: Finder
EAN-13: 8012823122748
Order Code: 51-0562
Country of Origin: Italy

Free UK shipping available

Inc VAT

Qty	Unit Price (Ex VAT)
1+	£32.28

Sign in for personalised pricing

Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT

Despatched same day - 3 in stockBack-order availability date - 28/10/2026

Product Details
Product Range
Data Sheets

A 16A 230V AC modular step relay with a SPST-NO + NC contact configuration. The relay module is just 17.4mm wide and is designed for standard 35mm DIN rail mounting.

17.4mm Wide
Test button with mechanical indicator
Identification label
Approvals: CE, cRUus, RINA, IMQ, NF, GOST, Lloyds

Type	Impulse changeover switch
Built-in depth	N/A
Coil Current	28mA
Coil Resistance	2500Ω
Coil Voltage	230V
Contact Configuration	SPST-NO
Function	Mechanical
Height	60.8mm
IP Rating	IP20
Length	84mm
Max. incandescent lamp load	2000W
Max. load fluorescent lamp	N/A
Max. load fluorescent lamp (Duo circuit)	N/A
Max. load fluorescent lamp (parallel compensated)	N/A
Max. switching current (cos phi = 0.6)	N/A
Mounting method	DIN rail
Mounting Type	Rail
Number of contacts as change-over contact	0
Number of contacts as normally closed contact	1
Number of contacts as normally open contact	1
Operating Temperature	-40 to +40°C
Rated current	16A
Supply Voltage	196 - 253V
Switching Current Max	16A
Switching Power	4000VA
Switching Voltage Max (AC)	400V
Type of control voltage 1	N/A
Type of control voltage 2	N/A
Voltage type (supply voltage)	AC
Width	17.5mm
Width in number of modular spacings	1
