Step Relay Finder 20.22.9.024.4000 24VDC 2NO Contacts

MPN: 20.22.9.024.4000
Brand: Finder
EAN-13: 8012823116464
Order Code: 51-0561

RoHS Compliant
Free UK shipping available

Inc VAT

Qty	Unit Price (Ex VAT)
1+	£21.70

Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT

Despatched within 4 working days - 323 in stock

Product Details

A 16A 24V DC modular step relay with a DPST-NO contact configuration. The relay module is just 17.4mm wide and is designed for standard 35mm DIN rail mounting.

17.4mm Wide
Test button with mechanical indicator
Identification label
Approvals: CE, cRUus, RINA, IMQ, NF, GOST, Lloyds

Type	Impulse changeover switch
Built-in depth	N/A
Function	Mechanical
IP Rating	IP20
Max. incandescent lamp load	2000W
Max. load fluorescent lamp	N/A
Max. load fluorescent lamp (Duo circuit)	N/A
Max. load fluorescent lamp (parallel compensated)	N/A
Max. switching current (cos phi = 0.6)	N/A
Mounting method	DIN rail
Number of contacts as change-over contact	0
Number of contacts as normally closed contact	0
Number of contacts as normally open contact	2
Rated current	16A
Supply Voltage	21.6 - 26.4V
Type of control voltage 1	N/A
Type of control voltage 2	N/A
Voltage type (supply voltage)	DC
Width in number of modular spacings	1
