Siemens manufactures the 6ES7212-1HE40-0XB0 PLC compact CPU, a versatile programmable logic controller designed for efficient automation tasks. This compact CPU offers robust performance, flexible connectivity, and is ideal for small to medium-sized industrial applications. It is commonly used in manufacturing, process control, and automation systems to enhance operational efficiency.
| Type |
PLC compact CPU |
| Additional program memory possible |
FALSE |
| Appendant operation agent (Ex ia) |
FALSE |
| Appendant operation agent (Ex ib) |
FALSE |
| Depth |
75mm |
| Explosion safety category for dust |
None |
| Explosion safety category for gas |
ATEX gas-ex-protection, Cat. 3G |
| Front built-in possible |
TRUE |
| Height |
100mm |
| Interfaces |
1 |
| IO link master |
FALSE |
| Memory Size |
100kB |
| Misc Attribute 1 |
6ES7212-1HE40-0XB0 |
| Misc Attribute 2 |
8 DI/6 DO/2AI |
| Mobile communications standard 3G (UMTS) |
FALSE |
| Model |
Compact |
| Number of Analogue Inputs |
2 |
| Number of Analogue Outputs |
0 |
| Number of Digital Inputs |
8 |
| Number of Digital Outputs |
6 |
| Number of HW-interfaces industrial Ethernet |
1 |
| Number of HW-interfaces other |
0 |
| Number of HW-interfaces parallel |
0 |
| Number of HW-interfaces RS-232 |
0 |
| Number of HW-interfaces RS-422 |
0 |
| Number of HW-interfaces RS-485 |
0 |
| Number of HW-interfaces USB |
0 |
| Number of HW-interfaces wireless |
0 |
| Number of interfaces PROFINET |
1 |
| Number of relay outputs |
6 |
| Number of relay outputs (max.) |
6 |
| Processing time (1K, binary operation) |
0.08ms |
| Rack-assembly possible |
TRUE |
| Radio standard Bluetooth |
FALSE |
| Radio standard GPRS |
FALSE |
| Radio standard GSM |
FALSE |
| Radio standard WLAN 802.11 |
FALSE |
| Redundancy |
FALSE |
| Suitable for rail mounting |
TRUE |
| Suitable for safety functions |
FALSE |
| Supporting protocol for ASI |
TRUE |
| Supporting protocol for AS-Interface Safety at Work |
FALSE |
| Supporting protocol for CAN |
FALSE |
| Supporting protocol for Data-Highway |
FALSE |
| Supporting protocol for DeviceNet |
FALSE |
| Supporting protocol for DeviceNet Safety |
FALSE |
| Supporting protocol for EtherNet/IP |
FALSE |
| Supporting protocol for Foundation Fieldbus |
FALSE |
| Supporting protocol for INTERBUS |
FALSE |
| Supporting protocol for INTERBUS-Safety |
FALSE |
| Supporting protocol for KNX |
FALSE |
| Supporting protocol for LON |
FALSE |
| Supporting protocol for Modbus |
TRUE |
| Supporting protocol for other bus systems |
TRUE |
| Supporting protocol for PROFIBUS |
TRUE |
| Supporting protocol for PROFINET CBA |
FALSE |
| Supporting protocol for PROFINET IO |
TRUE |
| Supporting protocol for PROFIsafe |
FALSE |
| Supporting protocol for SafetyBUS p |
FALSE |
| Supporting protocol for SERCOS |
FALSE |
| Supporting protocol for SUCONET |
FALSE |
| Supporting protocol for TCP/IP |
TRUE |
| System accessory |
TRUE |
| Type of memory |
RAM |
| Voltage type (supply voltage) |
DC |
| Wall mounting/direct mounting |
TRUE |
| Width |
90 |
| With display |
FALSE |
| With optical interface |
FALSE |
