Siemens 5SY42106 Circuit Breaker 10A 2-pole D 230/400V 10kA

The Siemens 5SY42106 Circuit Breaker is designed to provide overcurrent protection with a capacity of 10 A, suitable for both 230 V and 400 V systems. It is commonly used in residential and commercial electrical installations. This device ensures reliable operation, safeguarding circuits against overloads and short circuits.

Type	Circuit breaker
Current Rating	10a
Voltage Rating - AC	400V AC
No. of Poles	2
Tripping Characteristics	B Curve
Additional equipment possible	TRUE
Ambient temperature during operating	-40 - 70°C
Built-in depth	70mm
Circuit breaker type	Miniature circuit breaker
Compatible with (details)	SENTRON
Concurrently switching neutral conductor	FALSE
Connectable conductor cross section multi-wired	0.75 - 35mm²
Connectable conductor cross section solid-core	0.75 - 35mm²
Country of origin	Germany
Current limiting class	3
Current Ratng	10A
Degree of protection (IP)	IP20
Depth	76mm
Dim	(W x H x D) 36 x 90 x 76 mm
Explosion-proof	false
Factory colour	Grey
Flush-mounted installation	false
Frequency	50-60MHz
Height	90mm
Input Current	10 A
Input frequency	50/60 Hz
Input Voltage	400 V
International Protection (IP) code	IP20
Number of Pins	2
Number of Poles	2
Number of poles (total)	2
Number of protected poles	2
Operating temperature (T-T)	-40 - 70°C
Overvoltage category	3
Package depth	84mm
Package height	92mm
Package width	40mm
Pollution degree	3
Power loss	N/A
Product colour	Grey
Protection Class	III
Quantity per pack	1 pc(s)
Rated current	10A
Rated impulse withstand voltage Uimp	4
Rated insulation voltage Ui	440V
Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V	10kA
Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V	10kA
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V	20kA
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V	20kA
Rated voltage	400V
Switch-off Capacity	5kA
Voltage Rating	400V
Voltage type	AC
Weight	306g
Width	36mm
Width in number of modular spacings	2
