Siemens 5SV33126 RCCB 2-pin 25A 0.03A 230V FI-protection Switch

The Siemens 5SV33126 is a residual current circuit breaker (RCCB) with a 25 A current rating and a 0.03 A residual current operating level, designed to provide effective earth fault protection. This 2-pin RCCB is suitable for 230 V AC applications and is particularly useful for safeguarding electrical systems in residential and commercial installations. Its compact design ensures easy integration into various electrical panels.

Type	RCCB
Voltage Rating - AC	230V AC
Tripping Characteristics	A Curve
Additional equipment possible	true
Ambient temperature during operating	-25 - 45°C
Built-in depth	70mm
Circuit breaker type	Residual-current device
Connectable conductor cross section multi-wired	0.75 - 35mm²
Connectable conductor cross section solid-core	0.75 - 35mm²
Current Ratng	25A
Degree of protection (IP)	N/A
Depth	70mm
Differential current rating	0.03A
Dim	(W x H x D) 36 x 90 x 70 mm
Explosion-proof	false
Factory colour	Grey
Frequency	50 Hz
Height	90mm
Input Current	25 A
Input Voltage	230 V
International Protection (IP) code	IP20
Leakage current type	A
Misc Attribute	Design of the product: without delay; Mounting Type: DIN rail
Mounting method	N/A
Number of Pins	2
Number of Poles	2
Package depth	42mm
Package height	85mm
Package width	97mm
Pollution degree	2
Power loss	1W
Product colour	Grey
RAL-number (similar)	7035
Rated current	25A
Rated fault current	0.03A
Rated impulse withstand voltage Uimp	6kV
Rated insulation voltage Ui	2000V
Rated voltage	230V
Selective protection	false
Short-circuit breaking capacity (Icw)	10kA
Short-time delayed tripping	false
Surge current capacity	1kA
Switch-off Capacity	0.5kA
Voltage Rating	230V
Voltage type	AC
Weight	0
Width	36mm
Width in number of modular spacings	2
With interlocking device	true
