The Siemens RCBO 5SV1316-7KK16 is a circuit protection device rated at 16 A with a residual current of 0.03 A, suitable for 230 V systems. It combines the functionality of a miniature circuit breaker and a residual current circuit breaker, offering overcurrent and earth fault protection. Ideal for residential and commercial electrical installations, it ensures safety and prevents electrical hazards.
| Type |
RCBO |
| Current Rating |
16A |
| Voltage Rating - AC |
230V AC |
| Actuator Type |
Toggle |
| Tripping Characteristics |
C |
| Ambient temperature during operating |
N/A |
| Anti-nuisance tripping version |
TRUE |
| Breaking Capacity |
6000 A |
| Built-in depth |
70mm |
| Circuit breaker type |
Residual-current device with overcurrent protection (RCBO) |
| Compliance certificates |
CE, EAC, UKCA |
| Concurrently switching neutral conductor |
TRUE |
| Connectable conductor cross section multi-wired |
0.75 - 16mm² |
| Connectable conductor cross section solid-core |
0.75 - 16mm² |
| Country of origin |
Romania |
| Current limiting class |
3 |
| Current Ratng |
0.03A |
| Degree of protection (IP) |
IP20 |
| Depth |
70mm |
| Differential current rating |
0.03A |
| Dim |
(W x H x D) 18 x 90 x 70 mm |
| Disconnection characteristic |
Undelayed |
| Doesnt contain |
Halogen, Silicone |
| Flush-mounted installation |
true |
| Frequency |
N/A |
| Height |
90mm |
| Input Current |
16 A |
| Input frequency |
50/60 Hz |
| Input Voltage |
230/195 V |
| International Protection (IP) code |
IP20 |
| Leakage current type |
A |
| Misc Attribute |
Switch-off description: without delay |
| Number of pins |
1 |
| Number of Poles |
1 |
| Number of poles (total) |
2 |
| Number of protected poles |
1 |
| Operating relative humidity (H-H) |
0 - 95% |
| Operating temperature (T-T) |
-25 - 45°C |
| Overvoltage category |
2 |
| Package weight |
133g |
| Pollution degree |
2 |
| Power Dissipation |
3.4 W |
| Power loss |
N/A |
| Quantity per pack |
1 pc(s) |
| Rated current |
16A |
| Rated fault current |
0.03A |
| Rated impulse withstand voltage Uimp |
4 |
| Rated insulation voltage Ui |
253V |
| Rated short-circuit breaking capacity according to EN 61009 |
6 |
| Rated short-circuit breaking capacity according to IEC 60947-2 |
10kA |
| Rated short-circuit breaking capacity Icn according to EN 61009-1 |
6 |
| Rated voltage |
230V |
| Storage temperature (T-T) |
-40 - 75°C |
| Surge current capacity |
1kA |
| Switch-off Capacity |
6kA |
| Trip curve type |
Type C |
| Voltage Rating |
230V |
| Voltage type |
AC |
| Weight |
0 |
| Width |
18mm |
| Width in number of modular spacings |
1 |
| With interlocking device |
TRUE |
