The Siemens 5SV1316-7KK02 is an RCBO designed for reliable protection with 2-pin connectivity, supporting a 2 A current and 0.03 A residual current at 230 V. This device combines overcurrent and fault current protection, ensuring enhanced safety in electrical installations. It is typically used in residential or commercial settings for safeguarding circuits against overload and short circuit conditions.
| Type |
RCBO |
| Voltage Rating - AC |
230V AC |
| Actuator Type |
Toggle |
| Tripping Characteristics |
C |
| Ambient temperature during operating |
N/A |
| Anti-nuisance tripping version |
TRUE |
| Built-in depth |
70mm |
| Concurrently switching neutral conductor |
TRUE |
| Connectable conductor cross section multi-wired |
0.75 - 16mm² |
| Connectable conductor cross section solid-core |
0.75 - 16mm² |
| Current limiting class |
3 |
| Current Ratng |
0.03A |
| Degree of protection (IP) |
IP20 |
| Depth |
70mm |
| Differential current rating |
0.03A |
| Dim |
(W x H x D) 18 x 90 x 70 mm |
| Disconnection characteristic |
Undelayed |
| Flush-mounted installation |
true |
| Frequency |
N/A |
| Height |
90mm |
| Leakage current type |
A |
| Misc Attribute |
Switch-off description: without delay |
| Number of pins |
2 |
| Number of poles (total) |
2 |
| Number of protected poles |
1 |
| Overvoltage category |
2 |
| Pollution degree |
2 |
| Power loss |
N/A |
| Rated current |
2A |
| Rated fault current |
0.03A |
| Rated impulse withstand voltage Uimp |
4 |
| Rated insulation voltage Ui |
253V |
| Rated short-circuit breaking capacity according to EN 61009 |
6 |
| Rated short-circuit breaking capacity according to IEC 60947-2 |
10kA |
| Rated short-circuit breaking capacity Icn according to EN 61009-1 |
6 |
| Rated voltage |
230V |
| Surge current capacity |
1kA |
| Switch-off Capacity |
6 |
| Voltage Rating |
230V |
| Voltage type |
AC |
| Width |
18mm |
| Width in number of modular spacings |
1 |
| With interlocking device |
TRUE |
