Siemens 5SV13166LK16 Residual Circuit Breaker 16A 10mA 1 pole

Image Representative of Range

Siemens 5SV13166LK16 Residual Circuit Breaker 16A 10mA 1 pole

Siemens
Order Code:

07-0442

Brand: Siemens MPN: 5SV13166LK16 EAN-13: 4001869558073
Qty Unit Price (Ex VAT)
1+ £209.26
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Available to back orderBack order, lead time 11 days

The Siemens 5SV13166LK16 RCBO combines residual current protection and circuit breaking functionality in a single unit, providing enhanced safety and compact design. It features a 16A current rating and a 30mA residual current sensitivity, making it ideal for residential and commercial electrical installations. Commonly used in electrical distribution boards, it ensures protection against overloads, short circuits, and earth fault currents.
Type RCBO
Anti-nuisance tripping version TRUE
Built-in depth 70mm
Concurrently switching neutral conductor TRUE
Current limiting class 3
Degree of protection (IP) IP20
Disconnection characteristic Short-time delayed
Leakage current type A
Number of poles (total) 2
Number of protected poles 1
Overvoltage category 2
Pollution degree 2
Rated Current 16A
Rated fault current 0.03A
Rated impulse withstand voltage Uimp 4
Rated insulation voltage Ui 253V
Rated short-circuit breaking capacity according to EN 61009 6
Rated short-circuit breaking capacity according to IEC 60947-2 15kA
Rated short-circuit breaking capacity Icn according to EN 61009-1 6
Rated Voltage 230V
Release characteristic B
Surge current capacity 3kA
Voltage type AC
Width in number of modular spacings 1
With interlocking device TRUE
