Siemens 5SV13166KK06 RCBO 6A 230V 1P+N 6kA compact type A 30mA B6

Siemens manufactures the 5SV1316-6KK06 RCBO, a compact 2-pin device with a 6 A rating and a 0.03 A residual current trip level, designed for residential electrical safety. It operates at 230 V, providing protection by combining overcurrent and earth leakage detection. This RCBO is typically used in domestic and light commercial installations to prevent electrical faults and enhance safety.

Type	RCBO
Voltage Rating - AC	230V AC
Actuator Type	Toggle
Tripping Characteristics	B Curve
Ambient temperature during operating	N/A
Anti-nuisance tripping version	TRUE
Built-in depth	70mm
Concurrently switching neutral conductor	TRUE
Connectable conductor cross section multi-wired	0.75 - 16mm²
Connectable conductor cross section solid-core	0.75 - 16mm²
Current limiting class	3
Current Ratng	0.03A
Degree of protection (IP)	IP20
Depth	70mm
Differential current rating	0.03A
Dim	(W x H x D) 18 x 90 x 70 mm
Disconnection characteristic	Undelayed
Flush-mounted installation	true
Frequency	N/A
Height	90mm
Leakage current type	A
Misc Attribute	Switch-off description: without delay
Number of pins	2
Number of poles (total)	2
Number of protected poles	1
Overvoltage category	2
Pollution degree	2
Power loss	N/A
Rated current	6A
Rated fault current	0.03A
Rated impulse withstand voltage Uimp	4
Rated insulation voltage Ui	253V
Rated short-circuit breaking capacity according to EN 61009	6
Rated short-circuit breaking capacity according to IEC 60947-2	35kA
Rated short-circuit breaking capacity Icn according to EN 61009-1	6
Rated voltage	230V
Surge current capacity	1kA
Switch-off Capacity	6kA
Voltage Rating	230V
Voltage type	AC
Weight	0
Width	18mm
Width in number of modular spacings	1
With interlocking device	TRUE
