The Siemens 5SU13567KK16 switch is a residual current circuit breaker with a 16 A current rating, 0.03 A residual current, and a 230 V capacity. It combines the functions of a protective switch and circuit breaker, ensuring personal protection and preventing electrical faults. Typically used in residential and commercial settings, it provides enhanced safety by detecting and interrupting earth leakage currents.
| Type |
Switch |
| Ambient temperature during operating |
N/A |
| Anti-nuisance tripping version |
TRUE |
| Built-in depth |
70mm |
| Concurrently switching neutral conductor |
TRUE |
| Connectable conductor cross section multi-wired |
0.75 - 35mm² |
| Connectable conductor cross section solid-core |
0.75 - 35mm² |
| Current limiting class |
3 |
| Current Ratng |
0.03A |
| Degree of protection (IP) |
IP20 |
| Depth |
70mm |
| Differential current rating |
0.03A |
| Dim |
(W x H x D) 36 x 90 x 70 mm |
| Disconnection characteristic |
Undelayed |
| Flush-mounted installation |
true |
| Frequency |
N/A |
| Height |
90mm |
| Leakage current type |
A |
| Misc Attribute |
Switch-off description: without delay |
| Number of Pins |
2 |
| Number of poles (total) |
2 |
| Number of protected poles |
1 |
| Overvoltage category |
2 |
| Pollution degree |
2 |
| Power loss |
N/A |
| Rated current |
16A |
| Rated fault current |
0.03A |
| Rated impulse withstand voltage Uimp |
4 |
| Rated insulation voltage Ui |
264V |
| Rated short-circuit breaking capacity according to EN 61009 |
6 |
| Rated short-circuit breaking capacity according to IEC 60947-2 |
15kA |
| Rated short-circuit breaking capacity Icn according to EN 61009-1 |
6 |
| Rated voltage |
230V |
| Release characteristic |
C |
| Release characteristics |
C |
| Surge current capacity |
1kA |
| Switch-off capacity |
6 |
| Voltage Rating |
230V |
| Voltage type |
AC |
| Width |
36mm |
| Width in number of modular spacings |
2 |
| With interlocking device |
TRUE |
