Siemens 5SU13567KK06 Switch 6 A 0.03 A 230 V EPL for WinCC flexible

The Siemens 5SU13567KK06 switch is a residual current protective device with circuit breaker capabilities, rated at 6 A and 0.03 A for earth leakage, operating at 230 V. This RCBO is designed for personal protection against electrical faults by quickly disconnecting in case of an earth fault or overcurrent. Typical applications include use in residential and commercial electrical installations to enhance safety by protecting against electrical shocks and fire hazards.

Type	Switch
Voltage Rating - AC	230V AC
Tripping Characteristics	C
Ambient temperature during operating	N/A
Anti-nuisance tripping version	TRUE
Built-in depth	70mm
Concurrently switching neutral conductor	TRUE
Connectable conductor cross section multi-wired	0.75 - 35mm²
Connectable conductor cross section solid-core	0.75 - 35mm²
Current limiting class	3
Current Ratng	0.03A
Degree of protection (IP)	IP20
Depth	70mm
Differential current rating	0.03A
Dim	(W x H x D) 36 x 90 x 70 mm
Disconnection characteristic	Undelayed
Flush-mounted installation	true
Frequency	N/A
Height	90mm
Leakage current type	A
Misc Attribute	Switch-off description: without delay
Number of pins	2
Number of poles (total)	2
Number of protected poles	1
Overvoltage category	2
Pollution degree	2
Power loss	N/A
Rated current	6A
Rated fault current	0.03A
Rated impulse withstand voltage Uimp	4
Rated insulation voltage Ui	264V
Rated short-circuit breaking capacity according to EN 61009	6
Rated short-circuit breaking capacity according to IEC 60947-2	25kA
Rated short-circuit breaking capacity Icn according to EN 61009-1	6
Rated voltage	230V
Surge current capacity	1kA
Switch-off Capacity	6
Voltage Rating	230V
Voltage type	AC
Weight	0.27
Width	36mm
Width in number of modular spacings	2
With interlocking device	TRUE
