Siemens 3SU15001AA101NA0 emergency stop pushbutton red metal lock

Image Representative of Range

Siemens 3SU15001AA101NA0 emergency stop pushbutton red metal lock

Siemens
Standard range
Order Code:

06-9107

Brand: Siemens MPN: 3SU15001AA101NA0
Qty Unit Price (Ex VAT)
1+ £10.92
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
12 in stock, despatched in 4 working days

Siemens 3SU1500-1AA10-1NA0 is a triple module holder designed for holding auxiliary switch blocks and contact elements. It accommodates two switch makers and is ideal for use in control panels and signalling installations. This built-in device enhances the functionality and organisation of electrical control systems.
Type Triple module holder
Compatible with (details) 3 modules
Connection Screws
Contact type 2 makers
Dielectric strength 6kV
Dim (W x H) 30 mm x 40 mm
Durability 10
Height 40mm
IP rating IP20
Max. temperature +70°C
Min. temperature -25°C
Misc Attribute 1 3SU1500-1AA10-1NA0
Misc Attribute 2 3-way with module
Mounting Type Front panel fixed
Recess depth 49.8mm
RoHS-compliant Yes
Switching current (max.) 10A
Weight 42g
Width 30mm
