SEPA AD1224UB-F5B Axial Fan 24V DC 120x120x38.5mm 1Piece

SEPA
Order Code:

10-5880

Brand: SEPA MPN: 111111483 EAN-13: 2050006209783
Qty Unit Price (Ex VAT)
1+ £26.04
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
27 available to back orderBack-order availability date - 13/01/2026

The SEPA AD1224UB-F5B(N21Q) is an industrial cooling fan with dimensions of 120 x 120 x 38.5 mm, designed for 24 V DC operation. This axial fan is ideal for component cooling and is used in various applications requiring efficient air movement. Its robust build makes it suitable for both commercial and industrial environments.
Type Axial fan
Voltage 21.6 - 26.4 V
Dimensions (L x W x H) 120 x 120 x 38.5 mm
Bearing Type Ball bearing
Noise 56.6dB
Power (W) 9.6W
Height 38.5mm
IP Rating IP55
Length 120mm
Lifespan 70,000h
Max. current consumption 400mA
Max. operating voltage 26.4V
Max. temperature +70°C
Min. operating voltage 21.6V
Min. temperature -10°C
Misc Attribute AD1224UB-F5B(N21Q)
Number of wires 4
Rotational speed 3200 U/min
Width 120mm
