Self Electronics SLT30-24VLG-ES LED Driver 30W 24V Surge Protection Furniture

The Self Electronics SLT30-24VLG-ES LED driver is a constant voltage, 30 W power supply delivering 24.0 V DC and designed for use on furniture. It features robust surge protection and overvoltage safety, but is not dimmable. This unit is ideal for powering LED strips and other low-voltage lighting applications.

Type	LED driver
Output Voltage	24.0V DC
Max Output Power	30W
Output Current	0A
Input Voltage	264V AC
Connection	Screw terminal
Dimensions	(L x W x H) 165.00 x 40.00 x 30.00 mm
Height	30.00mm
IP Rating	IP20
Length	165.00mm
Max. output current	1.25A
Max. temperature	50°C
Min. input voltage	198V AC
Min. temperature	-20°C
Misc Attribute 1	Constant voltage
Misc Attribute 2	Synchronised
Number of Inputs	1
Number of Outputs	1
Operating Current	200mA
Power (min.)	0W
Test mark	CE; SELV,; MM; Intertek; CCC
Weight	200.00g
Width	40.00mm
