Self Electronics SLT30-24VLG-ES LED Driver 30W 24V Surge Protection Furniture

Image Representative of Range

Self Electronics SLT30-24VLG-ES LED Driver 30W 24V Surge Protection Furniture

Self Electronics
Standard range
Order Code:

10-5693

Brand: Self Electronics MPN: SLT30-24VLG-ES EAN-13: 4021087039352
Qty Unit Price (Ex VAT)
1+ £17.29
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
27 in stock, despatched in 4 working days

The Self Electronics SLT30-24VLG-ES LED driver is a constant voltage, 30 W power supply delivering 24.0 V DC and designed for use on furniture. It features robust surge protection and overvoltage safety, but is not dimmable. This unit is ideal for powering LED strips and other low-voltage lighting applications.
Type LED driver
Connection Screw terminal
Dim (L x W x H) 165.00 x 40.00 x 30.00 mm
Height 30.00mm
Input voltage (max.) 264V AC
IP rating IP20
Length 165.00mm
Max. output current 1.25A
Max. power 30W
Max. temperature 50°C
Min. input voltage 198V AC
Min. temperature -20°C
Misc Attribute 1 Constant voltage
Misc Attribute 2 Synchronised
No. of inputs 1
No. of outputs 1
Operating current 200mA
Operating voltage 230V AC
Output current (max.) - rounded 1.25A
Output current (min.) 0A
Output voltage (max.) 24.0V DC
Output voltage (min.) 24.0V DC
Power (min.) 0W
Power range 0 up to 30 W
Test mark CE; SELV,; MM; Intertek; CCC
Weight 200.00g
Width 40.00mm
