Self Electronics SLT100-48VFG-UN LED Driver 100W 48V Surge Protection

The Self Electronics SLT100-48VFG-UN LED driver provides constant voltage of 48 V DC with a power capacity of 100 W and surge protection features. It is suitable for flammable surfaces, approved for use on furniture, and is non-dimmable. Typical applications include powering LED strips and other LED lighting solutions.

Type	LED driver
Output Voltage	48V DC
Max Output Power	100W
Output Current	0A
Input Voltage	264V AC
Connection	Screw terminal
Dimensions	(L x W x H) 298 x 29.8 x 16.5 mm
Height	16.5mm
IP Rating	IP20
Length	298mm
Max. output current	2080mA
Max. temperature	+45°C
Min. input voltage	108V AC
Min. temperature	-20°C
Misc Attribute 1	Constant voltage
Misc Attribute 2	Pulsed
Number of Inputs	1
Number of Outputs	1
Protection Class	II
Test mark	CE · MM · SELV · ENEC · UL
Weight	216g
Width	29.8mm
