Self Electronics SLD40-900IL-ES LED Driver 39.6W 900mA 22-44V Dimmable

The Self Electronics SLD40-900IL-ES LED driver delivers a constant current of 900 mA and supports a power output of 39.6 W, operating at 22 - 44 V DC with dimmable functionality. It is suitable for use on flammable surfaces and includes surge protection and overvoltage safeguards, making it ideal for powering LED strips and other LED applications. This robust LED power supply unit is a reliable choice for maintaining optimal lighting in various settings.

Type	LED driver
Connection	Screw terminal
Dim	(L x W x H) 165 x 40 x 30 mm
Height	30mm
Input voltage (max.)	264V AC
IP Rating	IP20
Length	165mm
Max. output current	900mA
Max. power	39.6W
Max. temperature	40°C
Min. input voltage	198V AC
Min. temperature	-20°C
Misc Attribute	Constant current
Number of Inputs	1
Number of Outputs	1
Operating Current	210mA
Operating Voltage	230V AC
Output current (max.) - rounded	900mA
Output voltage (max.)	44V DC
Output voltage (min.)	22V DC
Power (min.)	19.8W
Power range	19.8 up to 39.6 W
Protection Class	II
Test mark	Getaktet
Width	40mm
