Self Electronics SLD40-800IL-ES LED Driver 40W 800mA 25-50V Dimmable

Self Electronics
Order Code:

10-5670

Brand: Self Electronics MPN: SLD40-800IL-ES EAN-13: 4021087047340
Qty Unit Price (Ex VAT)
1+ £21.50
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
50 in stock, despatched in 4 working days

The Self Electronics SLD40-800IL-ES LED driver provides a constant current of 800 mA and is rated at 40 W, suitable for applications requiring dimmable LED lighting between 25 - 50 V DC. It features surge protection and is designed for use on flammable surfaces. Typical applications include LED strips, making it a reliable choice for indoor or outdoor lighting installations.
Type LED driver
Connection Screw terminal
Dim (L x W x H) 165 x 40 x 30 mm
Height 30mm
Input voltage (max.) 264V AC
IP Rating IP20
Length 165mm
Max. output current 800mA
Max. power 40W
Max. temperature 40°C
Min. input voltage 198V AC
Min. temperature -20°C
Misc Attribute Constant current
Number of Inputs 1
Number of Outputs 1
Operating Current 210mA
Operating Voltage 230V AC
Output current (max.) - rounded 800mA
Output voltage (max.) 50V DC
Output voltage (min.) 25V DC
Power (min.) 20W
Power range 20 up to 40 W
Protection Class II
Test mark Getaktet
Width 40mm
