Self Electronics SLD30-12VL-E LED Driver 30W 12V Dimmable Flammable Safe

Self Electronics
Standard range
Order Code:

10-5662

Brand: Self Electronics MPN: SLD30-12VL-E EAN-13: 4021087047210
Qty Unit Price (Ex VAT)
1+ £29.24
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
58 in stock, despatched in 4 working days

The Self Electronics SLD30-12VL-E LED transformer is a dimmable, constant voltage LED driver with 30 W power, offering 2.5 A and 12 V DC output suitable for use on flammable surfaces. It features surge protection and overvoltage protection. Ideal for LED strip installation and other LED lighting applications.
Type LED transformer
Connection Screw terminal
Dim (L x W x H) 145 x 50 x 22 mm
Height 22mm
Input voltage (max.) 264V AC
IP rating IP20
Length 145mm
Max. output current 2.5A
Max. power 30W
Max. temperature 50°C
Min. input voltage 198V AC
Min. temperature -20°C
Misc Attribute 1 Constant voltage
Misc Attribute 2 Pulsed
No. of inputs 1
No. of outputs 1
Operating voltage 230V AC
Output current (max.) - rounded 2.5A
Output voltage (max.) 12V DC
Power range 30 W (max)
Protection class II
Weight 230g
Width 50mm
