Sealey PH5 Low Profile Engine Crane 0.5tonne

Low entry engine crane with a height of only 100mm at the wheels. Weighs only 37kg so is extremely lightweight and manoeuvrable. Heavy-duty castors and pump access from side, for safe handling of loads. Delivered in knock-down form, some self-assembly required.

• Low entry engine crane with a height of only 100mm at the wheels.
• Weighs only 37kg so is extremely lightweight and manoeuvrable.
• Heavy-duty castors and pump access from side, for safe handling of loads.
• Delivered in knock-down form, some self-assembly required.
• Model No. PH5

Type	Engine crane
Load Capacity	500kg
Height Jib Down	1330mm
Height Legs Folded	n/a
Height of Frame	100mm
Length	1210mm
Length Legs Extended	n/a
Length of Jib Position 1	750mm
Length of Jib Position 2	860mm
Length of Jib Position 3	980mm
Length of Jib Position 4	1100mm
Length of Jib Position 5	n/a
Lifting Capacity in Position 1	500kg
Lifting Capacity in Position 2	400kg
Lifting Capacity in Position 3	300kg
Lifting Capacity in Position 4	200kg
Lifting Capacity in Position 5	n/a
Max. Lift Ht at Jib Position 1	1950mm
Max. Lift Ht at Jib Position 2	2050mm
Max. Lift Ht at Jib Position 3	2150mm
Max. Lift Ht at Jib Position 4	2250mm
Max. Lift Ht at Jib Position 5	n/a
Nett Weight	37kg
Rear Width	550mm
Width Front Frame	800mm
Width Inside Front Frame	700mm
