Schneider Electric RSL1PRPU Relay Plug-in 230V AC/DC 6A 1 CO

Schneider Electric's RSL1PRPU plug-in relay operates at 230 V DC/AC and handles current up to 6 A. It features a single change-over contact, making it suitable for various switching applications. Commonly used in industrial and automation settings, this interface relay ensures reliable electrical control.

Type	Plug-in relay
Mounting Type	Plug-in
Height	101mm
Width	6.2mm
Length	101mm
Complete with socket	true
Connection	Spring-loaded terminal
Contact Material	AgSnO2
Contact Type	1 change-over
Degree of protection (IP)	IP40
Depth	78.6mm
Dim	(W x H x D) 6.2 x 101 x 78.6 mm
Drive, polarization	Polarity free
Drive, switching attitude	Mono stable
Durability	1000 0000 cycles
Factory colour	Anthracite (matt)
IP Rating	IP40
Material contact	Other
Material of contact insert	Other
Material of contact surface	Other
Max. starting current	N/A
Max. switching capacity	1500VA
Max. temperature	+70°C
Min. temperature	-40°C
Nominal Current	6A
Number of contacts as change-over contact	1
Number of contacts as normally closed contact	0
Number of contacts as normally open contact	0
Operating voltage AC 50 Hz	N/A
Operating voltage AC 60 Hz	N/A
Operating voltage DC	N/A
Rated control supply voltage AC 50 Hz	230 - 230V
Rated control supply voltage AC 60 Hz	230 - 230V
Rated control supply voltage DC	230 - 230V
Relay technology category according to IEC 61810-7	RT I
Type of electric connection	Spring clamp connection
Type of switch contact	Single contact
Voltage type (operating voltage)	N/A
Voltage type for actuating	AC/DC
Weight	29g
With detachable clamps	true
With forced-guided contacts	true
With LED indication	true
