Schneider Electric A9F04720 Acti9 Circuit Breaker 20A 400V IP20 C-type

The Schneider Electric A9F04720 circuit breaker is a 20 ampere device designed for over-current and short-circuit protection in electrical installations. It operates at a voltage of 400 V and is commonly used in residential and commercial applications to ensure safety and reliability. This miniature circuit breaker is part of the IC 60 range, known for its automatic operation and robust installation protection.

Type	Circuit breaker
Current Rating	20a
Voltage Rating - AC	400V AC
Additional equipment possible	true
Ambient temperature during operating	-35 - 70°C
Built-in depth	44.5mm
Concurrently switching neutral conductor	true
Connectable conductor cross section multi-wired	1 - 16mm²
Connectable conductor cross section solid-core	1 - 25mm²
Current limiting class	3
Current Ratng	20A
Degree of protection (IP)	IP20
Dim	(L x W x H) 78.5 x 72 x 91 mm
Explosion-proof	false
Factory colour	White
Flush-mounted installation	false
Frequency	50 - 60Hz
Height	91mm
Length	78.5mm
Number of Pins	3
Number of poles (total)	4
Number of protected poles	3
Overvoltage category	4
Pollution degree	3
Power loss	2.4W
Rated current	20A
Rated impulse withstand voltage Uimp	6kV
Rated insulation voltage Ui	500V
Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V	N/A
Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V	6kA
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V	20kA
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V	10kA
Rated voltage	400V
Release characteristic	C
Voltage Rating	400V
Voltage type	AC/DC
Width	72mm
Width in number of modular spacings	4
