Schneider Electric 15331 DIN rail timer 230V 7 days 1 channel

The Schneider Electric 15331 is a DIN rail mount analogue timer operating at 230 V. It is commonly used for automating lighting and heating systems in residential and commercial settings. This timer switch offers precise time management for electrical circuits.

Type	DIN rail mount timer
Size/ Dimensions	(L x W x H) 66 x 18 x 90 mm
Length	66mm
24 h program	false
60 min program	false
Accuracy per day	1s
Annual program	false
Automatic switching summer/winter time	false
Autonomy in hours	150
Autonomy in years	N/A
Channels	1-channel
Colour	White
Contact Type	N/A
Degree of protection (IP)	IP20
Depth	66mm
Frequency supply voltage	50 - 60Hz
Height	90mm
Mains synchronous	false
Max. switching power LED	300W
Misc Attribute 1	analogue
Mounting method	DIN rail
Nominal switching current at 250 V AC	16A
Number of Channels	1
Operating Voltage	230V
Potential free switch contact	true
Program shift divide 1	120min
Program shift divide 2	N/A
Quartz controlled	false
Shortest switching time channel 1	120min
Shortest switching time channel 2	N/A
Suitable for manual operation	true
Supply Voltage	230 - 240V
Switching preselection	true
Voltage type (supply voltage)	AC
Weekly program	true
Width	18mm
Width in number of modular spacings	1
