Image Representative of Range

Rose LM PRI-51/2 Monitoring Relay 24-240V AC/DC 1 Change-Over Heating Monitor

MPN: PRI-51/2
Brand: Rose LM
EAN-13: 8595188124911
Order Code: 10-5008
Country of Origin: Czech Republic

Free UK shipping available

Inc VAT

Qty	Was	Unit Price (Ex VAT)
1+	£42.46	£40.25
10+		£38.08
100+		£37.86

Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT

Available to back order

Product Details
Product Range
Data Sheets

The Rose LM monitoring relay PRI-51/2 operates with 24 to 240 V DC/AC and features a single change-over contact. Manufactured by Rose LM, this device is designed to monitor electrical parameters within this voltage range. It is typically used in industrial settings for ensuring the safety and functionality of electrical systems.

Type	Monitoring relay
Adjustment range (amperage)	0.2 - 2A
Amperage adjustment range (max.)	2A
Amperage adjustment range (min.)	0.2A
Connection	Screw terminal
Contact Material	AgNi
Contact Type	1 hange-over°C
Depth	64mm
Dim (W x H x D)	17.6 x 90 x 64mm
Functions	Current
Height	90mm
Maximum Temperature	+55°C
Min. temperature	-20°C
Operating Voltage	24, 24 - 24, 240 V DC, V AC
Switching current (max.)	8A
Width	17.6mm
