R-TECH 524571 19mm IP67 Vandal Resist Switch Black Blue LED SPDT

R-TECH
MPN
524571
Brand
R-TECH
EAN-13
5053556005833
Order Code
52-4571
Country of Origin
China
Qty Unit Price (Ex VAT)
1+ £13.48
10+ £11.92
25+ £11.06
50+ £10.67
100+ £10.32
250+ £9.98
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Despatched same day - 81 in stockContact us for additional availability

A stainless steel bodied tamper-proof switch designed to be resistant to accidental damage and attack by vandals. The switch has a black anodised body and features a blue LED illuminating ring that can be controlled by the switch or by external circuitry.

The switch is perfect for harsh use in potentially hostile settings such as public areas, industrial environments and building management applications. Suitable for installation in kiosks, lifts, pedestrian crossings and ticket machines. Provides a solution for requirements in extreme temperatures, dust, rain, snow, ice, dirt and moisture.


  • Max. switching current 5A AC
  • Switching voltage 250V AC
  • SPDT Contacts
  • Momentary operation
  • Blue LED ring
  • LED not polarity sensitive
  • Built-in LED resistor
  • Separate LED connections
  • Mounting diameter 19mm
  • Protection rating IP67
Type Push button
Contact Configuration Momentary
Switch Function 1 breaker
Current Rating 5A
Illumination Blue
Panel Cutout Dimensions 19mm
Illumination Type LED
IP Rating IP67
Max. switching current 5A AC
Maximum Temperature +55°C
Min. temperature -20°C
