PULS YR40.241 DIMENSION Redundancy Module 65A 1 Output High Performance

The PULS YR40.241 is a redundancy module designed for industrial power supply applications provided by the manufacturer PULS. It features one output and is capable of handling up to 65 A, making it suitable for various rugged environments. This module is rail mountable, commonly used in setting up reliable and uninterrupted power supply systems.

Type	Redundancy module
No. of Poles	1
Connection	Screw terminal
Dim	(L x W x H) 127 x 36 x 124 mm
Height	124mm
Length	127mm
Max. output current	65A
Maximum Input Volage	36.4V DC
Maximum Temperature	+70°C
Min. temperature	-40°C
Minimum Input Volage	8.4V DC
MTBF	2700000h
Number of Outputs	1
Output current (max.) - rounded	65A
Weight	340g
Width	36mm
