PTR Hartmann 54791100422D Spring-loaded Terminal 0.75 mm² 10 Pins Grey

PTR Hartmann 54791100422D Spring-loaded Terminal 0.75 mm² 10 Pins Grey

PTR
Order Code:

06-2919

Brand: PTR MPN: 54791100422D EAN-13: 2050001585325

Discontinued


The PTR Hartmann 54791100422D spring-loaded terminal is a basalt grey terminal block with 10 pins, ideal for PCB connections. Manufactured by PTR Hartmann, it features a 0.75 mm² screw terminal design offering secure electrical connections. This component is commonly used in electronic and industrial applications for creating reliable connections on printed circuit boards.
No. of Ways 10
No. of Levels 1
Voltage Rating 150V
Current Rating 6A
AWG (min.) 26
AWG max. 18
Connector orientation Parallel (to the PCB)
Contact Material Brass
Cross section (flexible) (max.) 0.75mm²
Cross section (flexible) (min.) 0.14mm²
Cross section (inflexible) (max.) 0.75mm²
Cross section (inflexible) (min.) 0.14mm²
CS 2.54mm
Factory colour Basalt grey
Height 16.20mm
Length 13.70mm
Min. stripping length 10mm
Misc Attribute AKZ4791/10KD-2.54-H
Pins per row 10
Series AKZ4791
Stripping length (max.) 10mm
Type Spring-loaded terminal
Width 27.94mm
Wire protection Yes
