PTR Hartmann 54191040051F Terminal Spring-loaded 0.75mm² 4 Pins Grey

Image Representative of Range

PTR Hartmann 54191040051F Terminal Spring-loaded 0.75mm² 4 Pins Grey

PTR
Order Code:

06-2896

Brand: PTR MPN: 54191040051F EAN-13: 2050001585097
Qty Unit Price (Ex VAT)
20+ £0.299
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Order in multiples of 1
73 in stock, despatched in 4 working days

The PTR Hartmann 54191040051F is a spring-loaded terminal designed for printed circuit boards, featuring a 0.75 mm² capacity and four pins. This pebble grey screw terminal block is ideal for establishing secure connections in electrical applications. Commonly used in various electronic devices, it offers reliable performance for circuit integration.
No. of Ways 4
No. of Levels 1
Voltage Rating 300V
Current Rating 2A
AWG (min.) 26
AWG max. 20
Connector orientation At an angle (to the PCB)
Contact Material Bronze
Cross section (flexible) (max.) 0.75mm²
Cross section (flexible) (min.) 0.14mm²
Cross section (inflexible) (max.) 0.75mm²
Cross section (inflexible) (min.) 0.14mm²
CS 2.50mm
Factory colour Pebble grey
Height 12.00mm
Length 11.50mm
Min. stripping length 9mm
Misc Attribute AK4191/4KDVP-2.5
Pins per row 4
Series AK4191
Stripping length (max.) 9mm
Type Spring-loaded terminal
Width 16.60mm
Wire protection Yes
