PTR Hartmann 50692020021E Screw Terminal 0.75 mm² 2 Pins Green 1 Piece

Image Representative of Range

PTR Hartmann 50692020021E Screw Terminal 0.75 mm² 2 Pins Green 1 Piece

PTR
Order Code:

06-2819

Brand: PTR MPN: 50692020021E EAN-13: 2050001584625
Qty Unit Price (Ex VAT)
20+ £0.239
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Order in multiples of 1
605 in stock, despatched in 4 working days

The PTR Hartmann 50692020021E is a green screw terminal designed for printed circuit boards with a conductor cross-section of 0.75 mm² and features two pins. It serves as a reliable PCB connector, facilitating secure electrical connections. This component is commonly used in electronic devices and equipment requiring robust terminal connections.
No. of Ways 2
No. of Levels 1
Voltage Rating 150V
Current Rating 7A
Actuation direction Perpendicular (to the PCB)
AWG (min.) 30
AWG max. 18
Connector orientation Parallel (to the PCB)
Contact Material Brass
Cross section (flexible) (max.) 0.75mm²
Cross section (flexible) (min.) 0.14mm²
Cross section (inflexible) (max.) 0.75mm²
Cross section (inflexible) (min.) 0.14mm²
CS 2.54mm
Factory colour Green
Height 6.50mm
Length 5.48mm
Min. stripping length 4mm
Misc Attribute AKZ692/2-2.54-V-GRÜN
Pins per row 2
Series AKZ692
Stripping length (max.) 4mm
Type Screw terminal
Width 12.00mm
Wire protection Yes
