Phoenix Contact 3273266 Distribution block 10pcs pull spring blue 15.6mm

The Phoenix Contact 3273266 distribution block features a 15.6 mm pull spring design, offering reliable connectivity and efficient distribution of electrical power. This blue block, ideal for use in switchboards and serial terminals, ensures continuity and secure connections. Typical applications include industrial control systems and electrical panel assemblies.

Type	Distribution block
Line Side Connections per Pole	2
Load Side Connections per Pole	2
Clamp width	15.6mm
Closing plate required	false
Colour	Blue
Connectable conductor cross section fine-strand with cable end sleeve	- - -mm²
Connectable conductor cross section fine-strand without cable end sleeve	- - -mm²
Connectable conductor cross section multi-wired	- - -mm²
Connectable conductor cross section solid-core	- - -mm²
Connection	Pull spring
Cross section (flexible) (min.)	0.14mm²
Cross section (inflexible) (min.)	0.14mm²
Current Rating	24A
Depth	21.7mm
Explosion-tested version Ex e	N/A
Flammability Rating	V0
Height	21.2mm
Inflammability class of insulation material according to UL94	V0
Internally connected stages	true
Length	28.2mm
Material insulation body	Thermoplastic
Misc Attribute	PTFIX 6X2,5 BU
Mounting method	N/A
No. of Rows	1
Nominal Voltage	500V
Number of clamp positions per level	6
Number of levels	1.0
Operating Temperature	- - -°C
Pins per row	6
Rated current In	24A
Rated voltage	450V
Suitable for conductor material	Aluminium/copper
Type of electrical connection 1	Other
Type of electrical connection 2	Other
Width	16mm
Wire Gauge (mm²)	2.50mm²
