Phoenix Contact 3240081 Ring Terminal 2.5mm² M8 Hole Dia8.4mm Non-Insulated

The Phoenix Contact 3240081 ring terminal is a metal crimp connector accommodating a cross-section of up to 2.50 mm² with a hole diameter of 8.4 mm. It is not insulated, making it suitable for applications like automotive or other solder-free connections. Supplied in packs of 100, this product is ideal for secure cable lugs in various electrical installations.

Colour	Metal
Insulated	Not insulated
Stud Size	8.4mm
Maximum Wire Size (mm2)	2.50mm²
According to DIN	false
AWG-range	- - -
Bolt dimension (metric)	N/A
Colour insulation	Other
Contact Material	Cathode copper, tin plated
Cross-section range	1 - 2.50mm²
Flange length	N/Amm
Flange shape	Ring shape
For pull protected connections	false
Halogen free	N/A
Hole Ø	8.4mm
Industrial packaging	Yes
Insulation	N/A
Material	Copper
max. cross section	2.50mm²
Max. current (Imax)	N/AA
Maximimum Wire Gauge (AWG)	14
Min. cross section	1mm²
Misc Attribute	C-RC 2,5/M8 DIN
Nominal cross section	1 - 2.5mm²
Pin diameter (pin shape terminal)	N/Amm
Pin width (flat-pin shape terminal)	N/Amm
Product Type	Ring Terminal
Reel/roll packaging	false
Sleeve form	N/A
Stud size (imperial)	N/A
Suitable for fine strand conductors	false
Suitable for flat conductors	false
Suitable for high temperatures (to 650 °C)	false
Suitable for insulated varnish	false
Suitable for round conductors	false
Suitable for solid conductors	false
Suitable for stranded conductors	false
Support sleeve	No
Surface protection	N/A
Thread Size	M8
Total Length	N/Amm
