Phoenix Contact 3044089 Din Rail Terminal Block Screw 5.2mm 32A Blue

This blue 5.2mm Din Rail screw terminal block from the Phoenix Contact UT series has a compact design and excellent handling. Standard contour earth conductor terminals are designed with a snap-in base. The double bridge shaft allows individual chain bridging using plug jumpers.

• UT 2,5 BU

Body Style	Horizontal
Closing plate required	true
Colour	Blue
Connectable conductor cross section fine-strand with cable end sleeve	0.14 - 0.14mm²
Connectable conductor cross section fine-strand without cable end sleeve	0.14 - 4mm²
Connectable conductor cross section multi-wired	0.14 - 1.5mm²
Connectable conductor cross section solid-core	0.14 - 4mm²
Current Rating	32A
Depth	46.9mm
Explosion-tested version Ex e	true
Height	47.7mm
Inflammability class of insulation material according to UL94	V0
Internally connected stages	true
Material insulation body	Other
Mounting method	DIN rail (top hat rail) 35 mm
No. of Levels	1
Number of clamp positions per level	2
Number of levels	1.0
Operating Temperature	-60 - 110°C
Rated current In	24A
Rated voltage	1000V
Suitable for conductor material	Aluminium/copper
Termination	Screw
Type of electrical connection 1	Screw connection
Type of electrical connection 2	Screw connection
Width	5.2mm
Wire Gauge (AWG)	12AWG
