Phoenix Contact 2961121 REL-MR-24DC/21AU PCB Relay 24V DC 6A 1 CO 1 piece

Phoenix Contact manufactures the REL-MR-24DC/21AU, a PCB relay with a 24 V DC coil voltage and a 6 A current rating, featuring one change-over contact. This mini relay is ideal for applications requiring compact and reliable switching on a printed circuit board. Common uses include industrial automation, control panels, and various electronic equipment.

Coil Voltage	24V DC
Contact Configuration	1CO (SPDT)
Switching Current	6A
Coil Resistance	3390O
Complete with socket	false
Connection	Solder pins
Contact Material	AgSnO + gold plating
Control Mode	monostable, 1 coil
Degree of protection (IP)	Other
Depth	15mm
Dimensions	(W x H x D) 5 x 28 x 15 mm
Drive, polarization	Polarity free
Drive, switching attitude	Mono stable
Height	28mm
Material contact	N/A
Material of contact insert	Other
Material of contact surface	Gold
Max. starting current	N/AA
Max. switching capacity	1500VA
Max. temperature	+85°C
Minimum Temperature	-40°C
Misc Attribute	REL-MR- 24DC/21AU
Mounting Type	PCB
Nominal Current	0.007A
Number of contacts as change-over contact	1
Number of contacts as normally closed contact	0
Number of contacts as normally open contact	0
Operating voltage AC 50 Hz	- - -V
Operating voltage AC 60 Hz	- - -V
Operating voltage DC	- - -V
Rated control supply voltage AC 50 Hz	- - -V
Rated control supply voltage AC 60 Hz	- - -V
Rated control supply voltage DC	14.4 - 66V
Relay technology category according to IEC 61810-7	N/A
Type	PCB relay
Type of electric connection	Other
Type of switch contact	Single contact
Voltage type (operating voltage)	N/A
Voltage type for actuating	DC
Width	5.0mm
With detachable clamps	false
With forced-guided contacts	false
With LED indication	false
