The Phoenix Contact 1935323 is a green screw terminal block with a 2.50 mm² capacity and three pins, ideal for secure connections. Its robust design makes it suitable for use on printed circuit boards in a variety of electronic and industrial applications. This component is perfect for environments that require reliable and durable electrical connection solutions.
| Pitch |
5mm |
| No. of Ways |
3 |
| Mounting Type |
Through Hole |
| Mounting Direction |
Vertical |
| Wire Gauge (AWG) |
26 - 14 AWG |
| Wire Termination |
Rising Clamp |
| Actuation direction |
Parallel (to the PCB) |
| Angle PCB/conductor connection |
N/A |
| AWG (min.) |
26 |
| Colour |
Green |
| Connectable conductor cross section fine-strand with cable end sleeve |
0.25 - 1.5mm² |
| Connectable conductor cross section fine-strand without cable end sleeve |
0.2 - 2.5mm² |
| Connectable conductor cross section multi-wired |
0.2 - 0.75mm² |
| Connectable conductor cross section solid-core |
0.2 - 2.5mm² |
| Connection type conductor |
Screw connection |
| Connection type PCB |
Soldering connection |
| Connector cross section |
2.5mm² |
| Contact Material |
Cathode copper, tin plated |
| Cross section (flexible) (max.) |
2.50mm² |
| Cross section (flexible) (min.) |
0.20mm² |
| Cross section (inflexible) (max.) |
2.50mm² |
| Cross section (inflexible) (min.) |
0.20mm² |
| CS |
5mm |
| Current Rating |
16A |
| Degree of protection (IP), mounted |
N/A |
| Diameter connection pin |
N/Amm |
| Enclosure material |
Polyamide |
| Factory colour |
Green |
| Fitting type (details) |
Solder |
| Height |
12.50mm |
| Housing Colour |
Green |
| Industrial packaging |
Yes |
| Inflammability class of insulation material according to UL94 |
V0 |
| Length |
11.40mm |
| Length pin |
3.5mm |
| Material connection surface |
Tin |
| Material insulation body |
Other |
| Min. stripping length |
5mm |
| Misc Attribute 1 |
Screw connection |
| Misc Attribute 2 |
PT 1,5/ 3-5,0-V |
| Modular spacing connections |
5mm |
| No. of Levels |
1 |
| Number of electrical connections |
3 |
| Number of levels |
1 |
| Operating Temperature |
-40 - 100°C |
| Overvoltage category |
III |
| Pins per row |
3 |
| Pollution degree |
2 |
| Rated current In |
17.5A |
| Rated Surge Voltage |
4kV |
| Rated voltage |
400V |
| Series |
PT |
| Stripping length (max.) |
5mm |
| Type |
Screw terminal |
| Type of banding |
Carton (for SMD) |
| Type of fastening |
Solder |
| Type of PCB fastening |
Connecting contact |
| Voltage Rating |
400V |
| Width |
15.00mm |
| Wire protection |
Yes |
