Phoenix Contact 1934874 COMBICON socket housing 3 pins 5mm spacing

The Phoenix Contact socket housing cable features three pins with a contact spacing of 5 mm. It is primarily used for secure and reliable connections in electronic and industrial applications. Ideal for connecting and terminating wires in various electrical projects.

Body Style	Socket, straight
Pitch	5mm
No of Ways Per Row	3
No. of Rows	1
Current Rating	10A
Wire Gauge (AWG)	14
Wire Gauge (mm²)	2.5mm²
Angle contact/conductor connection	Other
AWG (min.)	26
Coating housing	N/A
Connectable cable type	Tubular cable
Connectable conductor cross section fine-strand with cable end sleeve	0.25 - 1.5mm²
Connectable conductor cross section fine-strand without cable end sleeve	0.2 - 2.5mm²
Connectable conductor cross section multi-wired	- - -mm²
Connectable conductor cross section solid-core	0.2 - 2.5mm²
Connector cross section	2.5mm²
Connector System	wire-to-board
Contact Material	Tin plated
Contact Type	Bus
Degree of protection (IP), mounted	N/A
Dim	(L x W x H) 11.30 x 15.00 x 14.90 mm
Height	14.90mm
Housing Colour	Green
Housing Material	Other
Industrial packaging	Yes
Inflammability class of insulation material according to UL94	V0
Length	11.30mm
Material contact	Copper
Material insulation body	Polyamide (PA)
Material of contact surface	Tin
max. cross section	2.5mm²
Min. cross section	0.2mm²
Misc Attribute 1	PT 1,5/ 3-PVH-5,0
Misc Attribute 2	Screw connection
Modular spacing connections	5mm
Modular spacing contacts	5mm
Nominal Voltage	400V
Number of plug-in contact rows	1
Number of Poles	3
Operating Temperature	-40 - 100°C
Overvoltage category	III
Pollution degree	2
Rated current In	12A
Rated Surge Voltage	4kV
Rated voltage	400V
Series	PT
Stripping length (max.)	5.00mm
Total number of pins	3
Type	Socket housing cable
Type of connection	Other
Type of electric connection	Screw connection
Width	15.00mm
With protective conductor	N/A
